Shelly Pro 2PM
Shelly Pro 2PM
Couldn't load pickup availability
Professional 2-channel DIN rail smart switch with power metering & cover (roller shutter) control
Elevate your home or office with the Shelly Pro 2PM, the ultimate smart switch for controlling your roller shutters and measuring power usage. With its professional 2-channel DIN rail design, enjoy the convenience and energy efficiency this switch brings. Upgrade your space today!
- LAN, Wi-Fi, and Bluetooth connection
- 2 outputs, 16A each. Total device maximum of 25A (Maximum recommended 10A per circuit)
- Power metering on each channel and free storage data
- Cover (roller) control - roller shutters, awnings, gates, barriers, sliding doors, curtains, garage doors, bi-directional AC motors
- 1-phase control
- Easy control through the Shelly app, various protocols, and platforms, as well as voice assistant
As a one-phase, 2-channel relay, the Shelly Pro 2PM offers precise control and monitoring for devices with a capacity of up to 25A. With two integrated power meters and customizable scripting, this device is ideal for automating various fixtures, from shutters to gates, providing a convenient and efficient solution.
| PHYSICAL | |
|---|---|
| Size (HxWxD): | 94x19x69 ±0.5 mm |
| Weight: | |
| Mounting: | DIN rail |
| Screw terminals max torque: | 0.4 Nm / 3.54 lbin |
| Conductor cross section: | 0.5 to 2.5 mm² / 20 to 14 AWG (green connectors) 0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors) |
| Conductor stripped length: | 6 to 7 mm / 0.24 to 0.28 in (green connector) 5 to 6 mm / 0.20 to 0.24 in (blue connectors) |
| Shell material: | Plastic |
| Color: | Black |
| ENVIRONMENTAL | |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity | 30 % to 70 % RH |
| Max. altitude | 2000 m |
| ELECTRICAL | |
| Power supply voltage AC: | 110 - 240 V |
| Power supply voltage DC: | N/A |
| Power consumption: | < 3 W |
| Neutral not needed: | No |
| OUTPUT CIRCUITS RATINGS | |
| Max switching voltage AC: | 240 V |
| Max switching voltage DC: | N/A |
| Max switching current AC: | 16 A per channel, 25 A total (Maximum recommended 10A per circuit) |
| Max switching current DC: | N/A |
| SENSORS, METERS | |
| Voltmeter (AC) | Yes |
| Ammeter (AC) | Yes |
| Temperature sensor: | Yes |
| RADIO | |
| RF band: | 2400 - 2495 MHz |
| Max. RF power: | <20 dBm |
| Wi-Fi protocol: | 802.11 b/g/n |
| Wi-Fi Range: | Up to 30 m indoors and 50 m outdoors (Depends on local conditions) |
| Bluetooth Protocol: | 4.2 |
| Bluetooth Range: | Up to 10 m indoors and 30 m outdoors (Depends on local conditions) |
| MCU | |
| CPU: | ESP32-D0WDQ6 |
| Flash: | 8 MB |
| FIRMWARE CAPABILITIES | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | mJS |
| MQTT: | Yes |
| CoAP: | No |
Max Load is the Maximum rated Load and it is not recommended that this device is used for anything more than short duration at or near the Maximum.
Australia and New Zealand Safety Standard (AS/NZS) compliant, SDoC available on request.
