Lykalyte
Shelly Pro 1PM
Shelly Pro 1PM
Regular price
$158.99
Regular price
Sale price
$158.99
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Upgrade your home or office with Shelly Pro 1PM - the ultimate one-phase, 1-channel DIN rail relay. Measure power consumption, sync with daily activities, and customize automation scenes with scripting functionalities. Perfect for automated lights and heavy appliances, with support up to 16A. Experience a smarter and more efficient environment now!
- LAN, Wi-Fi, and Bluetooth connection
- 1 output, 16A
- Power metering
- Overpower and overvoltage protection of the load
- Easy control through the Shelly app, various protocols, and platforms, as well as voice assistants
Specifications
| PHYSICAL | |
|---|---|
| Size (HxWxD): | 94x19x69 m±0.5 m |
| Weight: | |
| Mounting: | DIN rail |
| Screw terminals max torque: | 0.4 Nm / 3.54 lbin |
| Conductor cross section: | 0.5 to 2.5 mm² / 20 to 14 AWG (green connector) 0.5 to 1.5 mm² / 20 to 16 AWG (blue connectors) |
| Conductor stripped length: | 6 to 7 mm (green connector) 5 to 6 mm (blue connectors) |
| Shell material: | Plastic |
| Color: | Red |
| ENVIRONMENTAL | |
| Ambient temperature: | -20 °C to 40 °C |
| Humidity | 30 % to 70 % RH |
| Max. altitude | 2000 m |
| ELECTRICAL | |
| Power supply voltage AC: | 110 - 240 V |
| Power supply voltage DC: | N/A |
| Power consumption: | < 3 W |
| Neutral not needed: | No |
| OUTPUT CIRCUITS RATINGS | |
| Max switching voltage AC: | 240 V |
| Max switching voltage DC: | N/A |
| Max switching current AC: | 16 A |
| Max switching current DC: | N/A |
| SENSORS, METERS | |
| Voltmeter (AC) | Yes |
| Ammeter (AC) | Yes |
| Temperature sensor: | Yes |
| RADIO | |
| RF band: | 2400 - 2495 MHz |
| Max. RF power: | <20 dBm |
| Wi-Fi protocol: | 802.11 b/g/n |
| Wi-Fi Range: | Up to 30 m indoors and 50 m outdoors (Depends on local conditions) |
| Bluetooth Protocol: | 4.2 |
| Bluetooth Range: | Up to 10 m indoors and 30 m outdoors (Depends on local conditions) |
| MCU | |
| CPU: | ESP32-D0WDQ6 |
| Flash: | 8 MB |
| FIRMWARE CAPABILITIES | |
| Schedules: | 20 |
| Webhooks (URL actions): | 20 with 5 URLs per hook |
| Scripting: | mJS |
| MQTT: | Yes |
| CoAP: | No |
Max Load is the Maximum rated Load and it is not recommended that this device is used for anything more than short duration at or near the Maximum.
Australia and New Zealand Safety Standard (AS/NZS) compliant, SDoC available on request.
