Shelly Plus UNI
Shelly Plus UNI
Regular price
$48.99
Regular price
Sale price
$48.99
Unit price
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Smart Wi-Fi-operated module
With its compact size and advanced capabilities, Shelly Plus UNI is perfect for low-voltage systems. It provides automation and monitoring features that are highly useful for a wide range of applications, making it the go-to choice for enhancing your home appliances.
- No hub required! Easy control through the Shelly Smart Control app, most platforms and protocols, as well as voice assistants. Use it with Alexa, Home Assistant, or your preferred automation platform
- Suitable for small appliances with low-voltage AC and DC applications (8-24 VAC, 9-28 VDC, and 5 VDC)
- Has two digital and 1 analog inputs
- Supports 1-Wire sensors (single DHT22 & up to 5 DS18B20)
- Compatible with most Arduino sensors! Use its digital or analog inputs to measure your desired parameters and create complex automation scenes based on the sensor data
- Receive precise data readings from your energy/gas/water meter (or any other meter that supports pulse count readings via external sensors)
- Wi-Fi Range Extender & BLE Gateway
- Extremely fast processor for immediate reaction - ESP32
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
Specifications
Dimensions (LxWxH)
37x42x16 mm (without the cables)
Weight
8.5 g
Ambient temperature
-20 °C to 40 °C
Humidity
30 % to 70 % RH
Power supply
8-24 VAC / 9-28 VDC / 5 VDC (stabilized, via +5 VDC and GND)
Power consumption
< 1 W
Digital inputs resistance
50 kΩ
Digital inputs triggering voltage
1.5 V (active low level)
Max switching voltage
30 V
Max switching current
250 mA
Voltmeter
0-15 VDC / 0-30 VDC (Two-range)
Pulse counter input triggering voltage
1.5 V (active low level)
Pulse counter max frequency
1 kHz
External sensors supported
Single DHT22 or up to five DS18B20
RF band
2400 - 2495 MHz
Max. RF power
< 20 dBm
Wi-Fi protocol
802.11 b/g/n
Wi-Fi operational range (outdoors)
up to 50 m
Wi-Fi operational range (indoors)
up to 30 m
Bluetooth protocol
4.2
Bluetooth operational range (outdoors)
up to 30 m
Bluetooth operational range (indoors)
up to 10 m
CPU
ESP32
Flash
4 MB
Schedules
20
Webhooks (URL actions)
20 with 5 URLs per hook
Scripting
Yes
MQTT
Yes
Australia and New Zealand Safety Standard (AS/NZS) compliant, SDoC available on request.
Shelly Smart Control App Google Play
Shelly Smart Control App Apple
