Shelly I4 Gen3
Shelly I4 Gen3
Couldn't load pickup availability
Typically used for:
- Scene activation
- Synchronized actions
- Complex trigger scenarios
The Shelly i4 Gen3 is a smart Wi-Fi switch input device that allows users to manually activate or deactivate scenes, run synchronized actions, and execute complex trigger scenarios. It can control other connected Shelly switches, sensors, or HTTP and MQTT-controlled devices. The device is compact enough to fit behind a standard wall switch and can show the status and control the action of four inputs. It has an improved processor and increased memory compared to its predecessor. The Shelly i4 Gen3 can be accessed and monitored remotely via the internet and has an embedded web interface for control and setup.
Control your devices directly from your smartphone or tablet using the intuitive mobile app. Connect Shelly i4 Gen3 to your Wi-Fi network for advanced home automation.
Key Features:
- 4 Digital Inputs: Control up to four independent inputs.
- Scene Activation: Activate or deactivate scenes.
- Smart Actions: Run synchronized actions.
- Trigger Scenarios: Execute complex trigger scenarios.
- Wi-Fi Connectivity: Connect to your Wi-Fi network.
Price
Single $XX.XX
Specifications
|
Physical |
|
|
Size (HxWxD): |
37x42x16 mm / 1.46x1.65x0.63 inch |
|
Weight: |
19 ±1 g / 0.67 ±0.04 oz |
|
Mounting: |
Wall box |
|
Shell material: |
Plastic |
|
Shell color: |
Blue |
|
Connectors color: |
Grey (Mouse Grey) |
|
Environmental |
|
|
Ambient working temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
|
Humidity: |
30 % to 70 % RH |
|
Max. altitude: |
2000 m / 6562 ft |
|
Electrical |
|
|
Power supply: |
110 - 240 VAC |
|
Power consumption: |
< 1 W |
|
Radio |
|
|
Wi-Fi |
|
|
Protocol: |
802.11 b/g/n |
|
RF band: |
2412 - 2472 МHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors (Depends on local conditions) |
|
Bluetooth |
|
|
Protocol: |
4.2 with BLE |
|
RF band: |
2402 - 2480 MHz |
|
Max. RF power: |
< 4 dBm |
|
Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors (Depends on local conditions) |
|
Microcontroller unit |
|
|
CPU: |
ESP-Shelly-C38F |
|
Flash: |
8 MB |
|
Firmware capabilities |
|
|
MQTT: |
Yes |
Max Load is the Maximum rated Load and it is not recommended that this device is used for anything more than short duration at or near the Maximum.
Higher loads require sufficient allowance for excess heat.
Australia and New Zealand Safety Standard (AS/NZS) compliant, SDoC available on request.
