Shelly BLU Motion ZB
Shelly BLU Motion ZB
Couldn't load pickup availability
Typically used for:
- Instant Motion-Activated Lighting & Hallway Navigation
- Dual Zigbee 3.0 & Bluetooth 5 LE Presence Integration
- Light-Aware Energy Management & Occupancy Automation
- Entryway Awareness & Subtle Security Scene Triggering
Add ultra-fast, cable-free motion and light detection to your smart home with the Shelly BLU Motion ZB (Model SBMO-103Z). Engineered with dual wireless connectivity, this compact sensor combines low-latency Zigbee 3.0 mesh networking with Bluetooth 5 LE capabilities. It functions seamlessly within standard Zigbee ecosystems, Home Assistant (via BTHome protocol), and the broader Shelly smart home platform without requiring any complex wiring or drilling.
Equipped with a Passive Infrared (PIR) motion sensor with adjustable sensitivity alongside an integrated LUX light sensor, the BLU Motion ZB tracks both activity and real-time room brightness. This allows you to set precise automations—such as turning on lights only when a space is both occupied and naturally dim. Powered by a high-capacity CR2477 coin cell battery, it provides up to 5 years of maintenance-friendly operation.
Key Features:
- Dual Zigbee 3.0 & Bluetooth 5 LE Protocols: Supports simultaneous Zigbee 3.0 networking and Bluetooth 5 LE (BTHome) broadcasting for ultimate platform flexibility.
- Integrated LUX Light Sensor: Features configurable dark, twilight, and bright levels with custom threshold points to restrict triggers to low ambient light conditions.
- Adjustable Motion Sensitivity: Tailor PIR responsiveness to avoid false triggers from pets or distant movement in high-traffic or quieter areas.
- Extended 5-Year Battery Life: Powered by a single 3V CR2477 battery (included) paired with the ultra-low-power Silicon Labs EFR32MG27 microcontroller.
- Versatile Surface & Swivel Mounting: Compact housing includes a flexible mounting base and tool-free double-sided adhesive for precise positioning on walls or ceilings.
Specifications
|
Physical |
|
|
Size (HxWxD): |
Sensor only: 28x37x37 mm | Sensor with mount: 28x44x42 mm |
|
Weight: |
Sensor only: 28 g | Sensor with mount: 33 g |
|
Mounting: |
Double-sided adhesive tape, mounting base (included) |
|
Shell material: |
Plastic |
|
Shell color: |
White |
|
Environmental |
|
|
Ambient working temperature: |
-20 °C to 40 °C |
|
Working humidity: |
30 % to 70 % RH |
|
Electrical & Power |
|
|
Power supply: |
1 x 3 V CR2477 battery (included) |
|
Battery life: |
Up to 5 years |
|
Sensors & Features |
|
|
Motion sensor: |
Passive Infrared (PIR) with adjustable sensitivity |
|
Light sensor (LUX): |
Yes (Configurable Dark, Twilight, Bright thresholds) |
|
Visual indication: |
Red LED flash on motion detection (can be disabled in settings) |
|
Radio & Connectivity |
|
|
Zigbee protocol: |
Zigbee 3.0 (IEEE 802.15.4) |
|
Zigbee frequency / RF power: |
2405 - 2480 MHz | < 8 dBm |
|
Bluetooth protocol: |
Bluetooth 5.0 LE (BTHome support) |
|
Bluetooth frequency / RF power: |
2400 - 2483.5 MHz | < 8 dBm |
|
Wireless range: |
Up to 10 m indoors | Up to 30 m outdoors (depending on local building materials) |
|
Gateway / Platform compatibility: |
Shelly Plus, Pro, Gen3, Gen4 series; standard Zigbee 3.0 hubs; Home Assistant (BTHome / Zigbee) |
|
Microcontroller Unit & System |
|
|
Model / Hardware ID: |
SBMO-103Z | Bluetooth ID: 0x0013 |
|
CPU / Flash memory: |
EFR32MG27 | 768 kB Flash |
|
Security & Features: |
AES Encryption (CCM mode), Beacon Mode support |
*NOTICE! This device supports both Zigbee 3.0 and Bluetooth LE. For full Zigbee integration, a compatible Zigbee 3.0 hub or controller is required. Bluetooth features can function via Shelly Plus/Pro/Gen3/Gen4 gateways or BTHome receivers.
Australia and New Zealand Safety Standard (AS/NZS) compliant. SDoCs are available upon request for declared articles sold by Lykalyte. Some components and non-declared products may not require SDoCs under NZ regulations.
