Shelly 2PM Gen4
Shelly 2PM Gen4
Couldn't load pickup availability
Typically used for:
- Covers & Blinds
- Power Monitoring
- Lights
- Appliances
Upgrade your space with the Shelly 2PM Gen4 ANZ, a professional-grade 2-channel smart relay designed for precise automation and real-time energy analytics. Perfect for motorized covers, roller shutters, blinds, curtains, awnings, or dual-lighting circuits, this small form factor device retrofits seamlessly into standard electrical wall boxes behind light switches or power sockets.
Control your connected equipment directly from your smartphone or tablet using the intuitive mobile app. Connect Shelly 2PM Gen4 ANZ directly to your Wi-Fi network to build a reliable, integrated smart ecosystem with native Matter and Zigbee compatibility.
Key Features:
- Dual-Channel Control: Supports 2 channels on the same phase, ideal for multi-zone lighting or bidirectional AC motor control.
- Advanced Cover & Slat Control: Automate and adjust the precise position of roller shutters, blinds, and gates, including venetian blind tilt/angle adjustment.
- Precise Power Metering: Independent, real-time consumption monitoring on each channel with free historical data storage.
- Multi-Protocol Connectivity: Native Wi-Fi, Bluetooth, Zigbee, and certified Matter compatibility out of the box.
- Smart Edge Hub: Functions as a Wi-Fi/Zigbee range extender and local Bluetooth gateway for the wider smart ecosystem.
- Advanced Customization: Supports complex schedules, scripting, virtual components, webhooks, MQTT, and local HTTP APIs.
Specifications
|
Physical |
|
|
Size (HxWxD): |
37x42x16 mm (±0.5 mm) |
|
Weight: |
30 g |
|
Mounting: |
Wall box |
|
Screw terminals max torque: |
0.4 Nm |
|
Conductor cross section: |
0.5 to 4 mm² (solid, stranded, and bootlace ferrules) |
|
Conductor stripped length: |
6 to 7 mm |
|
Shell material: |
Plastic |
|
Shell color: |
Black |
|
Terminals color: |
Grey (Mouse Grey) |
|
Environmental |
|
|
Ambient working temperature: |
-20 °C to 40 °C |
|
Humidity: |
30 % to 70 % RH |
|
Max. altitude: |
2000 m |
|
Electrical |
|
|
Power supply: |
110-240 V~ / 24 V⎓ ±10% |
|
Power consumption: |
< 1.4 W |
|
External protection: |
Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3) |
|
Output circuits ratings |
|
|
Max. switching voltage: |
240 V~ / 30 V⎓ |
|
Max. switching current AC: |
10 A per channel, 16 A total (18 A total peak) |
|
Max. switching current DC: |
10 A |
|
Sensors, meters |
|
|
Voltmeter (AC): |
Yes |
|
Ammeter (AC): |
Yes |
|
Internal-temperature sensor: |
Yes |
|
Radio |
|
|
Wi-Fi |
|
|
Protocol: |
802.11 b/g/n/ax |
|
RF band: |
2412 - 2472 MHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 50 m outdoors and 30 m indoors (depending on local conditions) |
|
Bluetooth |
|
|
Protocol: |
5.0 |
|
RF band: |
2402 - 2480 MHz |
|
Max. RF power: |
< 4 dBm |
|
Range: |
Up to 30 m outdoors and 10 m indoors (depending on local conditions) |
|
Zigbee |
|
|
Protocol: |
802.15.4 |
|
Zigbee repeater: |
Yes |
|
RF bands: |
2400 to 2483.5 MHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 300 m outdoors and 100 m indoors (depending on local conditions) |
|
Microcontroller unit |
|
|
CPU: |
ESP-Shelly-C68F |
|
Flash: |
8 MB |
|
Firmware capabilities |
|
|
Schedules: |
20 |
|
Webhooks (URL actions): |
20 with 5 URLs per hook |
|
Scripting: |
Yes |
|
MQTT: |
Yes |
Max Load is the Maximum rated Load and it is not recommended that this device is used for anything more than short duration at or near the Maximum.
Higher loads require sufficient allowance for excess heat.
Australia and New Zealand Safety Standard (AS/NZS) compliant. SDoCs are available upon request for declared articles sold by Lykalyte. Some components and non-declared products may not require SDoCs under NZ regulations.
