Shelly 1 Gen3
Shelly 1 Gen3
Couldn't load pickup availability
Typically used for:
- Lights
- Heating & Cooling
- Appliances
- Doorbell
- Irrigation
- Garage Doors / Security Gates
Upgrade your home and office with Shelly 1 Gen3, now equipped Shelly's own chip. Easily automate lighting, garage doors, and more for a smarter, efficient space. Its versatility makes it perfect for a variety of automation projects. Trust our expertise in creating a connected environment.
Control your devices directly from your smartphone or tablet using the intuitive mobile app. Simply connect the Shelly 1 Gen3 Relay to your Wi-Fi network, and you'll have the ultimate experience of managing your home with ease, all from the convenience of your phone.
Now with the added functionality of Bluetooth to assist with adding devices quickly and easily.
Harness the power of voice control by integrating the Shelly 1 Relay with popular voice assistants such as Google Home and Amazon Alexa. Just use your voice to command your appliances easily.
Create custom schedules for your devices with weekly scheduling. Whether it's turning on the lights at specific times or setting up a routine, the Shelly 1 Gen3 Relay empowers you to tailor automation to your preferences.
Experience the intelligence of Shelly Relays as they automatically adjust to daylight. With the ability to follow the sunrise and sunset hours, you can enjoy a seamless transition of your devices turning on and off based on natural lighting conditions.
Designed to handle a wide range of devices and appliances, the Shelly 1 Gen3 Relay supports up to 3500W of power. From lighting fixtures to various electrical appliances, you can confidently control them all.
The Shelly 1 Gen3 is compatible with a wide range of AC and DC power supplies, including 110–240V AC, 12V DC, and 24–48V DC. This versatility ensures that the Shelly 1 Gen3 Relay can adapt to your specific power requirements without any hassle.
Upgrade your home with the Shelly 1 Gen3 Relay and enjoy the perfect blend of intelligence, convenience, and compatibility in one small but powerful device.
- Dry contacts (potential-free) - option for contactor control
- New processor - ESP-Shelly-C38F chip with an increased memory of 8 MB
- Improved durability of terminals
- Wi-Fi range extender & Bluetooth gateway
- Supports scripting, webhooks, MQTT, WebSocket, HTTPS, UDP, TLS and custom certificates
- No HUB required! Easy control through Shelly Smart Control app, various home automation protocols, platforms, as well as voice assistants
- Supports KNXnet / IP communication
Price
Single $49.99
Specifications
|
Physical |
|
|
Size (HxWxD): |
37x42x16 / 1.46x1.65x0.63 |
|
Weight: |
26 g / 0.92 oz |
|
Screw terminals max torque: |
0.4 Nm / 3.5 lbin |
|
Conductor cross section: |
0.2 to 2.5 mm² / 24 to 14 AWG (solid, stranded, and bootlace ferrules) |
|
Conductor stripped length: |
6 to 7 mm / 0.24 to 0.28 in |
|
Mounting: |
Wall console |
|
Shell material: |
Plastic |
|
Shell color: |
Blue |
|
Terminal Color: |
Black |
|
Environmental |
|
|
Ambient working temperature: |
-20 °C to 40 °C / -5 °F to 105 °F |
|
Humidity: |
30 % to 70 % RH |
|
Max. altitude: |
2000 m / 6562 ft |
|
Electrical |
|
|
Power supply: |
|
|
Power consumption: |
< 1.2 W |
|
External protection: |
Cable protection switch in accordance with EN60898-1 (tripping characteristic B or C, max. 16 A rated current, min. 6 kA interrupting rating, energy limiting class 3) |
|
Output circuits ratings |
|
|
Max. switching voltage: |
|
|
Max. switching current: |
|
|
Sensors, meters |
|
|
Internal-temperature sensor: |
Yes |
|
Radio |
|
|
Wi-Fi |
|
|
Protocol: |
802.11 b/g/n |
|
RF band: |
2401 - 2483 МHz |
|
Max. RF power: |
< 20 dBm |
|
Range: |
Up to 30 m / 100 ft indoors and 50 m / 160 ft outdoors |
|
Bluetooth |
|
|
Protocol: |
4.2 with BLE |
|
RF band: |
2400 - 2483.5 MHz |
|
Max. RF power: |
< 4 dBm |
|
Range: |
Up to 10 m / 33 ft indoors and 30 m / 100 ft outdoors |
|
Microcontroller unit |
|
|
CPU: |
ESP-Shelly-C38F |
|
Flash: |
8MB |
|
Firmware capabilities |
|
|
Schedules: |
20 |
|
Webhooks (URL actions): |
20 with 5 URLs per hook |
|
Scripting: |
Yes |
|
MQTT: |
Yes |
Max Load is the Maximum rated Load and it is not recommended that this device is used for anything more than short duration at or near the Maximum.
Higher loads require sufficient allowance for excess heat.
Australia and New Zealand Safety Standard (AS/NZS) compliant, SDoC available on request.
